PCSB4-8-4Y Pan-Lug 8-Port Double Sided Multi-Tap Connector, 14 to 4 AWG Stranded, 14 to 10 AWG Aluminum/Copper/Solid Solid/Stranded Conductor, Screw Installation, Aluminum/PVC
- MFR:
- Panduit
- MFR #:
- PCSB4-8-4Y
- UPC:
- 074983599172
- Item #:
- 997129
PCSB4-8-4Y Pan-Lug 8-Port Double Sided Multi-Tap Connector, 14 to 4 AWG Stranded, 14 to 10 AWG Aluminum/Copper/Solid Solid/Stranded Conductor, Screw Installation, Aluminum/PVC
- MFR #:
- PCSB4-8-4Y
- UPC:
- 074983599172
- Item #:
- 997129
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$76.551
each
The PCSB4-8-4Y Multi-Tap Mechanical Lug has a flexible design that can be used as a tap, splice, or dead-end Lug. Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance. Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion. UL Listed and CSA Certified.
Manuals and Documentation
| Catalog Number | PCSB4-8-4Y |
| Manufacturer | Panduit |
| Brand | Panduit |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | Aluminum or Copper Code Conductors |
| Insulation | Clear PVC |
| Material | Aluminum / Clear PVC |
| Standard | UL listed and CSA certified for use up to 600V & Temperature Rated to 90 Degrees C |
| UPC | 074983599172 |
| GTIN | 00074983599172 |
| Item Type | Double-Sided Multi-Tap Connector |
| Voltage Rating | 600 |
