GracePorts® Grace Technologies

P-XX-K3RD0 Type 4 Ethernet Port Connector, Panel Mount

MFR #:
P-XX-K3RD0
Item #:
93973
$209.07 each
Product Details

GracePorts® Ethernet Port Connector, Type 4, Panel Mounting

Manuals and Documentation

Features

  • IP65 enclosure rating
  • Size K housing
  • Low voltage (data), limited to 30 VDC
  • High voltage supply (for computer use only) 120 VAC, 15A (UL), 5A (CSA) , 230 to 240 VAC, 16A (CE only)
  • Cast aluminum base housing
  • Type 304 stainless steel latch (1CR18NI19)
  • Polycarbonate, UV rated, V-O flame rated cover
  • Thermoplastic elastomer gasket
  • Acrylic UL94 HB insert
  • RJ45 F/F bulkhead connector
  • NEMA 12/4 rated housing
  • ThruView™ housing
  • 3.54 in H x 5.08 in W x 1.6 in D

Specifications

Identifiers

Identifiers
Manufacturer Part Number
P-XX-K3RD0

General Information

General Information
Manufacturer
Grace Technologies
Brand
GracePorts®
General Information
Country Of Origin
US
Standards Approvals
UL E207344 | CSA LR110845 | CE EN61010/EN60950 | RoHS Compliant | UR Listed

Technical Information

Technical Information
Mounting Type
Panel
Technical Information
Type
Type 4
