XCSE5312 Preventa Rectangular Safety Interlock Switch, 24/48 V DC, 6 A, 3 Poles
- MFR:
- YAGEO Corporation
- MFR #:
- XCSE5312
- UPC:
- 785901749370
- Item #:
- 494399
XCSE5312 Preventa Rectangular Safety Interlock Switch, 24/48 V DC, 6 A, 3 Poles
- MFR #:
- XCSE5312
- UPC:
- 785901749370
- Item #:
- 494399
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$840.42
each
Telemecanique Preventa™ Safety Interlock Switch, Rectangular, 24/48 V DC, 6 A, 10 VA, 3 Pole, NEMA 4/4X/12/IP67, Metal, 5.75 in H x 3.86 in W x 1.73 in D
Manuals and Documentation
Features
- Key operated turret head
- Slow-break, break before make contacts operation
- 1NC 2NO contacts type and composition
- 1NC 1NO (slow break, simultaneous) solenoid contacts type and composition
- 2-entries tapped M20 x 1.5 cable entry
- Locking on de-energization and unlocking on energization of solenoid
- 0.28 to 0.51 in Dia cable
- Terminal, 1 x 0.5 to 2 x 1.5 sq-mm with or without cable end electrical connection
- 10 gn 11 ms conforming to IEC 60068-2-27 shock resistance
- 2 LEDs green or orange (guard open/guard closed and locked) local signaling
- With NC contacts positive opening
- 1-load factor
- Greater than or equal to 1000000 cycles mechanical durability
- 0.03 ft/sec minimum actuation speed
- 1.64 ft/sec maximum actuation speed
- 50 V for signaling circuit conforming to EN/IEC 60947-1 rated insulation voltage
- 6 kV conforming to EN/IEC 60947-5 1 rated impulse withstand voltage
- 10 A cartridge fuse type gG (gl) short circuit protection
- Greater than or equal to 20 N actuator force for extraction
- 10 cycles/min for maximum durability operating rate
| Manufacturer Part Number | XCSE5312 |
| Brand | Telemecanique |
| Manufacturer | YAGEO Corporation |
| UPC | 785901749370 |
| EAN | 3389110719574 |
| Country Of Origin | ID |
| Amperage Rating | 6 A |
| Dimensions | 5.75 in H x 3.86 in W x 1.73 in D |
| Enclosure Type | NEMA 4/4X/12/IP67 |
| Material | Metal |
| Type | Rectangular |
| Voltage Rating | 24/48 V DC |
| Alternative Part Number | 9583918 |
| Manufacturer Item Status | Active |
| Country | USA/Canada |
| Warranty | 18 Months |
| Standards Approvals | RoHS CompliantCSA C22.2 No. 14 | EN/ISO 12100 | EN 1088/ISO 14119 | EN/IEC 60947-5-1 | EN/IEC 60204-1 | UL 508 | PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP) which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Application | Indoor/Outdoor Applications |
| Number Of Poles | 3 |
| Power Rating | 10 |
