Snap switch, 9007AO, metal roller plunger head, 15A at 120VAC, 1NO/1NC, open type
Snap switch, 9007AO, metal roller plunger head, 15A at 120VAC, 1NO/1NC, open type
| Location | Available Qty |
|---|---|
| Available | Available to Order |
Industrial snap switches are used as the electrical contacts within many control circuits and products. This snap switch has a steel bushing mounted roller plunger. This snap switch has one normally open and one normally closed snap action contacts. Contacts have an A600 inductive rating and 15A resistive rating. They also have 15A at 125VAC, 10A at 240VAC, 6A at 480VAC and 5A at 600VAC ratings. They also have 0.5A at 125VDC, 0.2A at 250VDC and 0.2A at 600VDC ratings. This snap switch is 2.50 inches tall, 0.83 inches wide and 2.69 inches deep. Snap switch is NEMA 1 and IP20 rated. Snap switch is UL component recognized and CSA certified. It supports non oil tight panel mounting. The 9007 series limit switches are designed to withstand harsh industrial environments and are available in a wide range of options.
Manuals and Documentation
- Catalog Number
- 9007AP321
- Manufacturer
- Telemecanique Sensors
- Brand
- Telemecanique
- Sub Brand
- 9007AO/CO
- Warranty Description
- Contractual Warranty:18 months
- Country of Origin
- France
- Made in USA
- No
- Action
- Linear;Snap action
- Actuator
- Spring return roller plunger steel bushing mounted;Plunger head;Traverse approach, 2 directions;Cast zinc
- Connection
- 1-2 6 binder head screw terminals AWG 22...AWG 14)
- Contact Configuration
- Form Z;NC-NO SPDT-DB
- Enclosure
- NEMA 1 NEMA TYPE 250
- Material
- Metal;Cast zinc
- Mounting
- Panel Mount
- Number of Poles
- 1
- Special Features
- 1...2 CABLES FOR 6 BINDER HEAD SCREW TERMINALS (AWG 22...AWG 14),IP20 CONFORMING TO IEC 60529
- Standard
- IP20 IEC 60529
- UPC
- 785901809418
- GTIN
- 00785901809418
- Item Type
- Snap limit switch
- Size
- 2.69
- Operating Temperature
- -20-185 A Degrees F
- Voltage Rating
- 600V
