Vacuum switch, 9016G, electromechanical, adjustable scale, 2 thresholds, Set 0 to 28.7InHg

MFR #:
9016GAW1Z16
UPC:
785901053798
Item #:
155302
$472.80 each
Product Details

9016GAW vacuum switches are provided with double throw contacts, normally open and normally closed circuits allow these controls to be used for standard or reverse action applications.

Manuals and Documentation

Features

  • 9016GAW vacuum switches for use in control circuit applications for both standard or reverse action applications
  • 1/2-14 NPT (internal) conduit connection
  • 1/4-18 NPTF (internal)
  • 0 to 28.7 in Hg

Specifications

Identifiers

Identifiers
Manufacturer Part Number
9016GAW1Z16
GTIN
00785901053798
Identifiers
UPC
785901053798
EAN
0785901053798

General Information

General Information
Manufacturer
Schneider Electric
Brand
Square Dâ„¢
Country Of Origin
MX
Warranty
18 Months
General Information
Standards Approvals
ECCN EAR99 | CE Certified | IEC 60957.5.1/68-2-6/58-2-27CSA 3211-03/File LR25490 | REACH Compliant | RoHS Compliant | UL 508/698/File E12158 CCN NKPZ and CCN NTHT | PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP) | which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP) | which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov
Application
Sensitive Control Applications
Includes
(2) Mounting Screws

Technical Information

Technical Information
Actuator
Diaphragm
Amperage Rating
10 A
Connection Type
Screw Clamp
Contact Configuration
1CO 1 Form Z SPDT
Enclosure Type
NEMA 4/4X/13
Environmental Conditions
Water Tight, Dust Tight, oiltight and Corrosion Resistant Indoor/Outdoor
Technical Information
Material
Die Cast Aluminum Alloy
Operating Cycles
120 cpm
Operating Temperature
-10 to 185 deg F
Series
9016
Type
Type GAW
Voltage Rating
480 V AC
