TargetLock E68-SVSSD1-BLP Diffuse Reflective Integral Right Angle Zero Pressure Accumulation Logic Sensor, 40 in, Visible Red Sensing Beam, 25 ms Response, Solid State Relay Output
- MFR:
- Eaton
- MFR #:
- E68-SVSSD1-BLP
- UPC:
- 782116014347
- Item #:
- 1478250
TargetLock E68-SVSSD1-BLP Diffuse Reflective Integral Right Angle Zero Pressure Accumulation Logic Sensor, 40 in, Visible Red Sensing Beam, 25 ms Response, Solid State Relay Output
- MFR #:
- E68-SVSSD1-BLP
- UPC:
- 782116014347
- Item #:
- 1478250
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$973.35
each
The E68 Series Integral Sensor Valve (ISV) from Eaton’s electrical sector is a complete Zero Pressure Accumulation (ZPA) sensing and control solution. This system solves the problem of product damage and mishandling caused by mechanical sensor rollers on outdated ZPA conveyors.
Manuals and Documentation
Features
- Self-contained package includes sensor, logic, air valve and wiring
- Non-contact, true zero pressure accumulation control without a PLC
- Low installation costs
- One touch air fittings for quick installation
- Low profile package allows easy integration into conveyor side channel
- System designed with sub 4 A, 24 VDC wiring for safety and reduced installation costs
- Easily interfaced to external control systems for singulated discharge and/or slug release
- Highly optimized, low cost power supply
- Red valve status on when air valve is open
- Diffuse reflective operating mode
- 3 ft sensing range 0.2 to 2 ft optimum range
- 0.2 in Dia at 2 in field of view
| Manufacturer Part Number | E68-SVSSD1-BLP |
| Brand | EATON |
| Manufacturer | Eaton |
| UPC | 782116014347 |
| Country Of Origin | MX |
| Amperage Rating | 100 mA |
| Enclosure Type | NEMA 1/4 |
| Series | E68 |
| Type | Diffuse Reflective Integral Right Angle Zero Pressure Accumulation |
| Voltage Rating | 18 to 30 V DC |
| Wattage | 1.35 W |
| Size | 3.36 in L x 1.4 in W x 4.4 in H |
| Alternative Part Number | 7402376 |
| Manufacturer Item Status | Active |
| Country | USA |
| Warranty | 3 Years |
| Standards Approvals | UL Listed,Contact Manufacturer |
| Application | Stationary Machinery, Equipment and In Factory Applications |
| Connection Type | 4-Pin M12 |
| Frequency Rating | 18.2 Hz |
| Light Source | LED |
| Operating Temperature | 14 to 131 deg F |
| Output Type | Solid State Relay |
| Response Time | 25 ms |
| Sensing Beam | Visible Red |
| Sensing Method | Polarized Retroreflective |
| Sensing Range | 40 in |
| Vibration | 30 g Over 10 Hz to 2 kHz |
