Product Details
WAGO, 2857-401, Isolation Amplifier, 250 V Input, 120 mA Input Current, Push-In Connection, 35 mm DIN Rail Mounting, Specifications: 9 millimeter Length, 4.331 in H x 0.492 in W x 4.213 in D Dimensions
Features
- Analog unipolar/bipolar signals at both input and output
- Digital signal output reacts to configured measurement range limits (configurable on/off switching delay and threshold value switch function with up to two threshold values)
- Digital HOLD input freezes the output signal
- Clipping capability for analog signal limitation to output end values
- Adjustable software/hardware filter
- Input/output response simulation via configuration display
Specifications
Identifiers
| Manufacturer Part Number |
2857-401
|
|---|
| EAN |
4050821676966
|
|---|
General Information
| Manufacturer |
WAGO Corporation
|
|---|---|
| Brand |
WAGO
|
| Standards Approvals |
EN 60664-1 | EN 61373 | EN 50121-3-2 | RoHS Compliant | CE | IP20
|
|---|
Dimensions
| Dimensions |
4.331 in H x 0.492 in W x 4.213 in D
|
|---|
Technical Information
| Connection Type |
Push-In
|
|---|---|
| Input Current |
120 mA
|
| Input Voltage |
250 V
|
| Mounting Type |
35 mm DIN Rail
|
|---|---|
| Specifications |
9 millimeter Length
|
