SDN-C Series Compact DIN Rail Power Supply, Nominal Output Current: 5 A (120 W), Nominal Voltage Input: 380/480 Vac, Nominal Voltage Output: 24 V, Frequency 50/60 Hz, PhaseThree Phase
MFR: SolaHD
MFR #: SDN5-24-480C
UPC: 783472006557
Item #: 76800
SDN-C Series Compact DIN Rail Power Supply, Nominal Output Current: 5 A (120 W), Nominal Voltage Input: 380/480 Vac, Nominal Voltage Output: 24 V, Frequency 50/60 Hz, PhaseThree Phase
MFR #: SDN5-24-480C
UPC: 783472006557
Item #: 76800
Availability
| Location | Available Qty |
|---|---|
| Available | 14 |
$898.77
each
Manuals and Documentation
- Catalog Number
- SDN5-24-480C
- Manufacturer
- SolaHD
- Brand
- SolaHD
- Country of Origin
- Philippines
- Made in USA
- No
- Application
- Industrial Machine Control and Process, Conveying Equipment, Material Handling, Packaging Equipment
- Cable Size
- 16 - 10 AWG Solid
- Frequency Rating
- 50/60
- Material
- Metal Housing
- Mounting
- Din Rail
- Phase
- 3
- Special Features
- Compact packaging to save space on the DIN rail, Visual diagnostic LEDs for input and output status at a glance, High MTBF means high reliability and long life, Higher efficiency saves energy and lowers amount of heat generated in panel, PowerBoostTM overload capability to start high inrush loads, Accepts Universal voltage 85-264 Vac, 50/60 Hz input, Active Power Factor Correction, Patented DIN rail mounting clip, User Adjustable output voltage accessible via front face, Parallel capability standard, Large, rugged, accessible screw terminals.
- Standard
- UL (CANADA AND US), UL 508, UL 60950, CUL, CSA-C22.2, CE
- UPC
- 783472006557
- GTIN
- 00783472006557
- Item Type
- SDN-C Compact DIN Rail Series
- Length
- 4.36
- Width
- 2.36
- Height
- 4.85
- Environmental Conditions
- 90 RH Humidity Range
- Voltage Rating
- 380 - 400
- Wattage
- 23.6
